40.500 Lt - 345 BBL Rolec Stainless Steel Ice Water Tank
40.500 Lt - 345 BBL Rolec Stainless Steel Ice Water Tank
or
Call 832-521-8010
Description
40.500 Lt - 345 BBL Rolec Stainless Steel Ice Water Tank
Pressure: Pressureless.
Temperature: 50C.
Max permissible density: 1.100 kg/m3.
Isolation: Perlite - mineral wool.
40.500 Lt - 345 BBL Tanque De Agua Helada De Acero Inoxidable Rolec
Presión: Sin presión.
Temperatura: 50C.
Densidad máxima permitida: 1.100 kg/m3.
Aislamiento: Perlita - lana mineral.
Specifications
| Manufacturer | Rolec Prozess-und Brautechnik GmbH |
| Year | 2013 |
| Condition | Used |
| Stock Number | 875947 |
| Serial Number | 12088-24 |
| Capacity of Tank | 10702.53 gal |
| Tank Material of Construction | STAINLESS STEEL |
| Grade of Stainless Steel | 304 |
| Jacketed | NO |
| Type of Top Head | CONE |
| Type of Bottom Head | CONE |
| Vertical or Horizontal | VERTICAL |
| Agitation | NO |
| Installation Type | LEGS |
| Outside Diameter | 125.98 in |
| Inside Diameter | 118.11 in |
| Overall Height | 278.50 in |
| Straight Side | 211.42 in |
| Recommended Packaging Form | CUSTOM PALLET |
| Dimensions | Standard |
| Overall | 126 x 126 x 279 IN - 7000 LBS |
